Industrial Grade Indoor Palm Size 5G CPE

To help you get started, we have provided you all the necessary documentation for your product.

SKU: X5125-50-102-48W-D Categories: , Tags: , , , , , , Brand:
Add to quote

Xatellite ST2 Datasheet 2025

Product Description

Xatellite ST2 is an industrial grade ruggedized, palm-sized indoor 5G CPE with ENOS system.

It is one of components from SDM platform, offering high performance routing and IPfiber tunnel capabilities. It can be deployed for IOT terminal devices, or provide a seamless data interconnection via IPfiber to help enterprises build their own private network simplistically.

Product Features

  • High Performance Quad-Core CPU
  • Dedicated Network Processing Unit Acceleration
  • Industrial Grade Ruggedized Aluminium Alloy Cover
  • Support 5G NR SA/NSA (3gpp R15), (Dual SIM, Single Pass, Single Standby)
  • Support Dual-Band WiFi6
  • PALM SIZE To Adapt To Different Environments
  • Across Network Overlay Pure L2 or L3 Tunnel
  • Support Terminal Control Platform Management

Weight 690 g
Dimensions 125 × 113 × 35 mm
Hardware

CPU, 64-bit Quad- Core ARMv8
NPU, Twelve-Threaded network processing unit
Form Factor, Aluminum alloy case
Mounting Kit Interface, 75 × 75 mm VESA mount
Cellula Network

Communication Standard, 3GPP Release 16 NSA/SA, operation sub-6 Ghz
Application Network, 5G NR SA, 5G NR NSA, LTE-FDD, LTE-TDD, WCDMA
5G NR Transmission Rate, "5G SA Sub-6: – Downstream 2.4Gbps – Upstream 900 Mbps 5G NSA Sub-6: – Downstream 3.4 Gbps – Upstream 550 Mbps"
4G LTE Transmission Rate, "CAT-19 Downstream 1.6 Gbps CAT-18 Upstream 200 Mbps"
"Network Frequency Band, 5G: Frequency Locking available (SA)" N1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79
"Network Frequency Band, 5G: Frequency Locking available (NSA)" N1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79
"Network Frequency Band, 4G: Frequency Locking available" B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/ 34/ 38/ 39/ 40/ 41/ 42/ 43/ 48/ 66/ 71
Antenna Connectors, 4 × 5G antennas (SMA)
